• 27 Horsepower V-Twin Kohler Command Pro Delphi® based Electronic Fuel Injection (EFI)
• OHV gasoline engine with horizontal crankshaft and pressure lube run cooler and provide longer service life
• Closed-loop EFI engine continually adjusts fuel ratio to use less fuel and provide reliable hot and cold starts, reduced exhaust emissions and fewer fuel-related service issues
• Automotive-style plug-in diagnostics
• Facilitates faster and more precise service

• Tandem 16cc Parker pumps-in-reservoir transmission with design-matched Parker high-torque wheel motors
• In-line CoolFan™ cooling system for cooling efficiency and long service intervals
• Delivers smooth response and requires less maintenance, with industry-leading 1,000-hour fluid change interval

• Extra-deep, 5.5-inch deck is fabricated from heavy-gauge formed steel with a reinforced anvil edge
• Specially designed cutting chambers enhance airflow for better cut quality
• Deck easily converts from side discharge to optional Down Discharge™ mulching or PowerVac™ collection
• Sentry™ spindles with massive, 8-inch flanges anchored in a 6-bolt pattern, spread the force of impact for greater strength
• Spindle planes are fabricated from double-layered formed steel laminate and combine with the spindles to form a triple-strength deck to keep blades level and deliver a high-quality cut.
• Sentry™ spindle guards shield spindle housing and seal lower bearings from fiber wrap and dirt ingestion

Standard on all FrontMount™ DuraMax® decks, PowerFold® is the zero-turn mower industry's first electric deck lift (introduced in 2004).

PowerFold® rotates the deck nearly 90 degrees to provide easy access to the underside of the deck for simplified maintenance and mulching package installation, plus space-saving portability and storage.

The feature also adjusts cutting height between 1.25 and 5.0 inches and controls deck lift functions using a single switch.

• The deep-cushioned, deluxe Premium Comfort Seat features a coil-spring suspension and padded lumbar support for all-day comfort. Iso-mounting eliminates vibration before it reaches the seat, and both padded seat and armrests are covered in scuff-resistant, breathable CoolTemp Cordura® fabric, which dissipates heat and won’t tear or crack with extended use.
• Operational controls including throttle, ignition and push/pull PTO switches, angled View-Eze™ console and adjustable cup holder are well positioned for visibility and ease of reach.
• One- or two handed operation with QuikAjust Tilt™ dual levers with 9-inch comfort range to custom fit operator's reach. Levers automatically return to neutral from either forward or reverse position and are less strenuous than riding mowers with steering wheels.

• Add or remove implements in minutes without tools with QuikConverter™ Implement System
• Equip your out-front mower with a wide range of tools, including turf cleanup, renovation and snow removal implements that extend your productivity year-round

Isolates the engine and T-Drive™ from the operator platform for an unprecedented vibration-free experience

• Fewer than 10 grease points and easy top-side access to belts and filters
• 1,000-hour transmission fluid change intervals
• Self-tensioning belts minimize cost and labor on routine maintenance

• Standard, low profile Roll-over Protection System (ROPS) structure with an adjustable seatbelt
• Dampened steering levers that return to neutral from forward and reverse
• Interlock switches that shut down the engine when the operator leaves the seat while PTO is engaged or levers are in drive position

• Robotically-welded, high-grade steel construction and I-beam reinforcement for long-lasting durability
• Centered-bearing design provides greater load-bearing capacity to easily handle the weight of operator, fuel and high-capacity collector with reserve strength for curb shocks and weight shifts
• Tough-as-nails powder-coated finish is fusion-bonded for chip and rust resistance

LED work lights provide improved visibility in low light situations.

ENGINE

DURAMAX® DECKS

STARTER & ELECTRICAL SYSTEM

ULTIMATE OPERATOR STATION

TRANSMISSION & STEERING

TIRE SIZES

DIMENSIONS

WEIGHT

• Commercial Use: 3-year unlimited hours; limited warranty: First two years covering parts and labor; third year covering parts only.
• Residential Use: 4-year or 800-hour (whichever comes first); limited warranty covering parts and labor.

PowerVac® FrontMount Collection System

Powerful, deck-driven PowerVac™ collection systems deliver one-pass perfection every time, and are available with a wide range of twin or triple mesh bag or high-capacity metal hopper collectors.

Armrest Height Adjustment Switch

Used in conjunction with PowerFold® electric deck lift/height adjustment, this armrest-mounted switch controls deck lift functions and adjusts cutting height between 1.0 and 4.5 inches on the go.

Rear Discharge Shield Kit

Optional rear discharge shield kit converts 34R Series decks to direct clippings out the back of the deck for a smooth cut and no windrowing.

SpeedTrimming™ Roller Kit

The optional SpeedTrimming™ heavy-duty, anti-scalp roller kit for 52-inch and larger DuraMax® decks speeds close trimming near buildings, fences retaining walls and other landscaping features. Kits available for both left and right sides of cutting decks.

Full Flotation Deck Inserts

Allow for controlled side-to-side flotation of the deck in rolling terrain for a smooth, even cut.

Hydraulic Deck Lift

Raises the front of the deck to maneuver over soft or uneven ground and to clear curbs, trailer ramps and other obstacles. Lift switch is standard in lever on current models. Kit includes Universal Wiring Harness and requires 50-lb. counterweight and counterweight mount kit.

QuikConverter® Implements

Every FrontMount™ mower accepts a range of time- and labor-saving QuikConverter™ implements for even greater flexibility and productivity year-round.

Your Choice of Decks

52-, 61- or 72-inch 34 Series DuraMax® and 61-inch 36 Series (3661) side-discharge decks easily convert to Down Discharge™ mulching or PowerVac™ collection. All come standard with PowerFold® electric deck lift/height adjustment.

52-, 61- or 72-inch 35R Series and 61-inch 37R Series (3761) dedicated rear discharge decks come standard with PowerFold® electric deck lift/height adjustment

Air Dam Kit

An optional Air Dam Kit can be installed along the front edge of most mower decks to minimize dust and dirt escaping from the front of the mower.

Wide Seat Conversion Kit

Provides additional seating room for larger operators or to accommodate cell phones or pagers. Requires seat belt extension.

WeatherBeater® Winter Enclosure

The full-view metal cab keeps moisture out and heat inside to keep the operator comfortable and productive. Standard electric windshield wiper clears windshield during operation. Powerful LED lights light up your path. Counterweight required.

Tail Wheel Options

Dual-fork tail wheels or wide stance single-fork tail wheels.

Yellow Beacon Light

Yellow beacon attaches to OPS to provide greater visibility in high-traffic areas.

Premier Suspension Seat

Optional premier suspension seat provides the ultimate in operator comfort. Low-profile seat slides fore and aft and includes an integrated shock absorber that manually adjusts to operators between 100 – 300 lbs. Other ergonomic features include a backrest that tilts from -5 degrees to +30 degrees, a lumbar support mechanism, adjustable armrests and a retractable seat belt.

Sunshade Canopy Vinyl

Lightweight, water repellent, UV-resistant vinyl canopy mounts easily to OPS or ROPS to limit exposure to direct sunlight, reducing eye strain and increasing operator comfort.

Down Discharge™ Mulching Package

The optional Down Discharge™ mulching package with GrassMax™ High-Low Mulching blades cuts and recuts clippings and directs them deep into the turf, enriching turf and producing a beautifully manicured cut.

Sunshade Canopy Aluminum

Diamond-plated aluminum canopy is highly resistant to abrasions. Mounts to ROPS or OPS to increase operator comfort by limiting exposure to direct sunlight and reducing eye strain. Canopy tilts up and down to accommodate operator’s size. Optional cooling fan and LED light kit increase operator comfort and visibility.

Extended Steering Levers

Provides an additional two inches of leg clearance.

Side Discharge Control Kit

Control the discharge of the mower deck to avoid putting clippings in flower beds and on sidewalks

Michelin® X® Tweel® Airless Tail and Deck Wheels

Smooth tread, 13x6.50x6 tail wheel. Performs like a pneumatic tire, but without the inconvenience and downtime associated with flats. Also available for 72-inch deck wheels. Not for use with PowerVac Collection Systems.

Dedicated Rear Discharge Decks

Dedicated, extra deep rear-discharge decks deliver revolutionary performance for applications where keeping clippings off sidewalks, driveways and parking lots is critical.

Michelin® X® Tweel® Airless Turf Tire

Optional 22 x 11.00-12 turf-tread drive tire performs like a pneumatic tire but without the inconvenience and downtime associated with flat tires. Provides consistent hub height to ensure the mower deck produces an even cut and excellent lateral stability and outstanding operator comfort.
