PRODUCTIVITY IN COMFORT
The V-Ride XL proves that it’s possible to be tough as nails and soft as a cloud. Its solid frame and expansive operator platform with an adjustable suspension to reduce vibration ensure you’re always riding in comfort no matter how big the job. Upgraded pumps and wheel motors are extra rugged and reliable, giving you confidence you’re always ready to tackle whatever comes your way.
Engine & Deck Combinations
| Model Number | Deck Width | Engine | Horsepower | |
|---|---|---|---|---|
SVRXL-52V-38FX-EFI  |
52″ | Kawasaki® FX Series EFI – electronic fuel injection | 38 | |
| SVRXL-52V-40BV-EFI |
52″ | Vanguard™ BIG BLOCK™ EFI – electronic fuel injection | 40 | |
| SVRXL-61V-38CV |
61″ | Kohler® Command PRO® | 38 | |
| SVRXL-61V-38FX-EFI |
61″ | Kawasaki® FX Series EFI – electronic fuel injection | 38 | |
| SVRXL-61V-40BV-EFI |
61″ | Vanguard™ BIG BLOCK™ EFI – electronic fuel injection | 40 | |
| SVRXL-72V-38FX-EFI |
72″ | Kawasaki® FX Series EFI – electronic fuel injection | 38 | |
| SVRXL-72V-40BV-EFI |
72″ | Vanguard™ BIG BLOCK™ EFI – electronic fuel injection | 40 |
Specifications
| Total Fuel Capacity | 12 gallons |
| Drive Tires | 24″ x 9.5″-12″ (52″) 24″ x 12″-12″ (61″ and 72″) |
| Caster Tires | 13″ x 6.5″-6″ |
| Drive System | |
| Drive System Type | Dual Pump & Motor |
| Pumps | Hydro-Gear 16 cc |
| Motors | Hydro-Gear 18 ci |
| Forward Ground Speed | Up to 11.6 mph |
| Reverse Ground Speed | 5 mph |
| Parking Brake | Hand lever |
| Deck | |
| Cutting Widths | 52″, 61″ and 72″ |
| Type | Velocity Plus™ cutter deck |
| Cutting Height | 2″ to 6″ in .25″ increments |
| Lift | Hand lever |
| Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. |
| Spindles | Cast-iron housing with tapered roller bearings |
| Blade Engagement | Ogura 3.5 (250 ft lb) Adjustable air-gap for extended life |
Product Dimensions
| Product Dimensions* | 52″ V-Ride XL | 61″ V-Ride XL | 72″ V-Ride XL |
|---|---|---|---|
| Length | 70.5″ | 73.5″ | 76″ |
| Tracking Width | 51.5″ | 53.2″ | 53.2″ |
| Width (chute down) | 65.25″ | 73.5″ | 83″ |
| Width (chute in transport position) | 53.75″ | 62.75″ | 73.75″ |
| Height | 47.75″ | 47.75″ | 47.75″ |
| Weight | 1,150–1,179 lb | 1,201–1,266 lb | 1,264–1,293 lb |
