Grasshopper Mowers

Grasshopper 400D

Grasshopper 400D

Deck Options
ROPS Options
Regular price $19,999.00 USD
Regular price $23,325.00 USD Sale price $19,999.00 USD
Sale Sold out

Fast and powerful to get the job done on time, every time.

The Grasshopper 400D 1.3L zero-turn lawn mower features the legendary power of a Kubota 3-cylinder MaxTorque™ Clean Diesel engine that delivers best-in-class torque and fuel economy. Commercial landscapes depend on Grasshopper mowers for their comfort, performance, productivity, quality and dependability.

Kubota Diesel Engine

  • EPA Tier 4 Final-compliant 77 cu. in. (1.3L) , 3-cylinder, liquid-cooled Kubota Clean Diesel engine with horizontal crankshaft and pressure lube for smooth, reliable operation

Heavy Duty Deck

  • Extra-deep, 5.5-inch deck is fabricated from heavy-gauge formed steel with a reinforced anvil edge
  • Specially designed cutting chambers enhance airflow for better cut quality
  • Deck easily converts from side discharge to optional Down Discharge™ mulching or PowerVac™ collection
  • Sentry™ spindles with massive, 8-inch flanges anchored in a 6-bolt pattern, spread the force of impact for greater strength
  • Spindle planes are fabricated from double-layered formed steel laminate and combine with the spindles to form a triple-strength deck to keep blades level and deliver a high-quality cut.
  • Sentry™ spindle guards shield spindle housing and seal lower bearings from fiber wrap and dirt ingestion

Ultimate Operator Station™

  • The deep-cushioned, deluxe Premium Comfort Seat features a coil-spring suspension and padded lumbar support for all-day comfort. Iso-mounting eliminates vibration before it reaches the seat, and both padded seat and armrests are covered in scuff-resistant, breathable CoolTemp Cordura® fabric, which dissipates heat and won’t tear or crack with extended use.
  • Operational controls including throttle, choke and angled View-Eze™ console and adjustable cup holder are well positioned for visibility and ease of reach
  • One or two hand steering system with QuikAjust Tilt™ dual levers with 9-inch comfort range that automatically returns the levers to the neutral position from the forward or reverse position.

    Hydraulic Height Adjustment

    • Hydraulic Height Adjustment for MidMount DuraMax™ decks 61-inches and larger allows operators to raise and lower cutting height at infinitely variable settings with toggle switch control. Standard on 400 Series models.

    Minimal Maintenance

    • Fewer than 10 grease points and easy top-side access to belts and filters
    • 1,000-hour transmission fluid change intervals
    • Self-tensioning belts minimize cost and labor on routine maintenance

    Reduced Maintenance

    • Only two Access-Eze™ lubrication points cut maintenance time up to 95%
    • Self-tensioning belts minimize cost and labor on routine maintenance

    Vigilant Operator Presence System™

    • Standard, low profile Roll-over Protection System (ROPS) structure with an adjustable seatbelt
    • Dampened steering levers that return to neutral from forward and reverse
    • Interlock switches that shut down the engine when the operator leaves the seat while PTO is engaged or levers are in drive position

    Design-Matched G2 Transmission

    • Rugged G2 transmission with auxiliary cooling fans, HydroGear variable displacement 21 cc piston-type pumps and high-torque Parker wheel motors
    • CoolFan™ hydro cooling system with 7-micron absolute filter for cooling efficiency
    • Delivers smooth response and requires less maintenance, with industry-leading 1,000-hour fluid change interval

      Rugged Construction

      • Robotically-welded steel construction for long-lasting durability
      • Centered-bearing design provides greater load-bearing capacity to handle the weight of operator, fuel and high-capacity collector with reserve strength for curb shocks and weight shifts
      • Tough-as-nails powder-coated finish is fusion-bonded for chip and rust resistance

      High Temperature Clutch Cut Out

      • Equipped with a High Temperature Clutch Cut-Out that automatically disengages the PTO if engine temperature reaches a certain point to prevent engine damage

      Premier Suspension Seat

      Premier suspension seat provides the ultimate in operator comfort. Low-profile seat slides fore and aft and includes an integrated shock absorber that manually adjusts to operators between 100 – 300 lbs. Other ergonomic features include a backrest that tilts from -5 degrees to +30 degrees, a lumbar support mechanism, adjustable armrests and a retractable seat belt.

      Specifications

      ENGINE

      Type/Horsepower/Cylinders
      Kubota, 3-cyl., MaxTorque™

      Displacement
      77 cu. in. (1261 cc)

      Lubrication System
      Pressure Lube/Filter

      Crankshaft
      Horizontal

      Cooling System
      Liquid

      Fuel
      Diesel - No. 2

      Fuel Capacity
      12 U.S. Gal. (45.4 l)

      Optional Fuel Capacity
      NA

      Air Cleaner
      Heavy-duty, remote mounted, cyclonic, dual element air filtration.

      Muffler
      Ultra quiet, single, industrial type

      DURAMAX® DECKS

      DECK
      DuraMax

      Mulching Package #
      504569(61), 504571(72)

      DURAMAX® DECK SIZE
      – 61" Deck
      *
      – 72" Deck
      *

      CUTTING HEIGHT RANGE
      1.0 to 5.0 in. (2.5cm to 12.7 cm)

      CONSTRUCTION (Robotic-welded steel)
      Double-layered 10-gauge plus 7-gauge formed-steel laminated spindle plane 0.313 in (7.95 mm) thick- more than 25% thicker than 0.25 in. (6.35 mm) with 7-gauge skirts for geometric strength. Spindle plane is 0.9 in.(22.86 mm) thick in stress zones. Anvil-edge design with 0.5 in. (12.7 mm) reinforcement on front edge of deck.

      BLADES (Tempered, alloy steel)
      – 61" Deck
      (3) 21 in. (53.3 cm)
      – 72" Deck
      (3) 25 in. (63.5 cm)

      SPINDLE ASSEMBLIES
      Sentry™ Spindle System, 2.5 cm (approx. 1 in.) O.D. shaft. Double bearings greasable from top of deck. Spindle head designed to eliminate fiber wrap. Spindle cones shield housing and lower bearings from fiber wrap and dirt ingestion.

      SPINDLE HOUSINGS
      8 in. (20.3 cm)-diameter housing with 6-bolt pattern. Machined aluminum housing. Cast iron on 72-inch deck.

      BLADE DRIVE
      Belt drive with single Kevlar V-belt and idler arm tensioning.

      STARTER & ELECTRICAL SYSTEM

      Battery (maintenance-free)
      12 Volt

      Starter
      Solenoid shift

      Ignition
      Breakerless, diesel quick heat glow plug

      Interlock System
      Prevents engine start when PTO clutch is engaged or steering levers are in drive position. Allows operator dismount without engine shutdown only when PTO is disengaged and steering levers are locked in neutral.

      ULTIMATE OPERATOR STATION

      Seat
      Iso-mounted Premium Comfort Seat. Features include a high-back, deep-cushioned, foam-padded Cordura®-covered, padded arm rests, padded backrest with lumbar support, coil-spring suspension and embroidered Grasshopper logo on seat back.

      Suspension
      InFrame™ suspension with iso-mounted seat and footrest

      Console-mounted Instruments
      Low engine oil pressure, alternator, temperature and parking brake warning lights, engine temperature and volt gauges, combination electronic fuel gauge/hour meter, two USB charging ports, ignition, work lights, glow plug and push/pull PTO switches.

      Work Lights
      Standard - LED

      Hour Meter
      Standard

      TRANSMISSION & STEERING

      Type
      Design-matched G2 hydrostatic system with auxiliary cooling fans, HydroGear variable displacement 21 cc piston-type pumps and high-torque Parker wheel motors.

      Filtration/Hydro Fluid
      7 micron absolute, spin-on / Grasshopper CoolTemp Hydro-Max™ fluid withstands high and low temperature extremes for 1,000-hour change intervals.

      Speed
      0 - 11 mph (0 - 17.7 kph) forward 0 - 6.0 mph (0 - 9.7 kph) reverse

      Turning Radius
      True zero degree, turns within own length with counter-rotating, independently powered drive wheels.

      Steering
      One- or two-hand operation with adjustable HydraSmooth™ dual levers that automatically return to neutral from either forward or reverse position.

      Brakes
      Dynamic braking through hydrostatic transmission.

      Parking Brake
      Disc parking brakes, one for each drive wheel.

      Attachment Drive
      NA

      TIRE SIZES

      Drive Wheels - Standard (4-ply rated)
      – 61" Deck
      26x12x12 turf, 6-ply rated
      – 72" Deck
      26x12x12 turf, 6-ply rated

      Drive Wheels – Optional (4-ply rated)
      24x12.00x12 bar tread, 4-ply rated

      Front Wheels – All Models
      13x6.50x6; rib tread, pneumatic with greasable, double-sealed bearings to protect from grass wrap.


      DIMENSIONS

      Height (Seat Back)
      47.0 in. (119.4 cm)
      Height (Seat Cushion)
      31.5 in. (80.0 cm)
      Height (ROPS)
      69.5 in. (176.5 cm)
      Length (midmount w/ DuraMax® Deck - Mowing Position)
      – 61" Deck
      86.0 in. (218.4 cm)
      – 72" Deck
      89.5 in. (227.3 cm)
      Deck Width (Side Discharge)
      – 61" Deck
      74.5 in. (189.2 cm)
      – 72" Deck
      85.5 in. 227.3 cm)
      Deck Width (Mulch*)
      – 61" Deck
      62.5 in.* (158.8 cm)
      – 72" Deck
      73.5 in.* (186.7 cm)

      WEIGHT

      (Uncrated)
      – 61" Deck
      1450 lbs. (657.7 kg)
      – 72" Deck
      1540 lbs. (698.5 kg)


      Mulching Package
      – 61" Deck
      36 lbs. (16.3 kg)
      – 72" Deck
      44 lbs. (20.0 kg)

      Warranty

      • Commercial Use: 3-year unlimited hours; limited warranty: First two years covering parts and labor; third year covering parts only.
      • Residential Use: 4-year or 800-hour (whichever comes first); limited warranty covering parts and labor.

      Options & Accessories

      Bar-Tread Low-Pressure Tires

      Optional low-pressure, high-flotation bar-tread tires flex with the terrain for maximum traction and minimize scuffing caused by wheel spin-out.

      LED Work Lights

      LED work lights provide improved visibility in low light situations.

      QuikAjust Tilt™ Levers

      Available for all MidMount models, optional QuikAjust Tilt™ steering levers (except 124V-41) with "no tools" adjustment provide a 9-inch range for maximum comfort and fit while maintaining natural arm and wrist positions..

      Yellow Beacon Light

      Yellow beacon attaches to OPS or ROPS to provide greater visibility in high-traffic areas.

      PowerVac® MidMount Collection System

      • PowerVac™ Collection Systems deliver a clean sweep on every pass. Simply adjust your mowing speed to your conditions.
      • Quik-D-Tatch® Vac drive can be removed in seconds without tools

      Custom Cordura® Weather Cover

      Weather-resistant, black Cordura fabric cover with embroidered Grasshopper logo keeps seat and engine area protected during storage or between mowings. Slips over ROPS, with Velcro closure to secure the opening.

      4X Rear Discharge Deck

      Dedicated 48--inch and larger rear discharge decks throw clippings out back for a smooth cut and no windrowing.

      SpeedTrimming™ Roller Kit

      The optional SpeedTrimming™ heavy-duty, anti-scalp roller kit for 61" and 72" DuraMax® decks (52" and 61" for Stand On decks) speeds close trimming near buildings, fences retaining walls and other landscaping features. Kits available for both left and right sides of cutting decks.

      Edge-EZE™ Edger

      Creates clean, sharp turf edges along sidewalks, roadways and driveways, eliminating time-consuming secondary trimming and reducing edging time up to 75 percent compared to hand-held string trimmers and walk-behinds.

      Shielded Sprayer

      Accepts 53-inch, 30-gallon shielded sprayer, which features aerodynamically designed shields and fully shielded curtains to contain chemical spray. Four-nozzle spraying chambers apply small droplets that "stick" to vegetation for more coverage per tank using less chemicals.

      Sunshade Canopy Vinyl



      Lightweight, water repellent, UV-resistant vinyl canopy mounts easily to OPS or ROPS to limit exposure to direct sunlight, reducing eye strain and increasing operator comfort.

      Radiator Cleaning Wand

      A multi-channel sprayer that combs water pressure between radiator fins without damage, dislodging packed-in dust and debris that can become an invisible source of engine overheating. Remove and clean radiator screen regularly. A dirty screen will cause the engine to overheat. For use on liquid-cooled models only.

      Down Discharge™ Mulching Package

      The optional Down Discharge™ mulching package with GrassMax™ medium-lift blades cuts and recuts clippings and directs them deep into the grass bed, enriching turf and producing a beautifully manicured cut.

      Foldable ROPS

      The Foldable ROPS allows the two-post ROPS to be lowered for mowing under low-hanging trees and other overhead obstacles, or for storing and transporting in enclosed trailers with low door clearance. CAUTION: Avoid drop-offs, embankments and steep slopes. Do not allow ROPS to provide a false pretense of security in hazardous areas and avoid questionable conditions. Always wear seatbelt when Foldable ROPS is in up-right position. When Foldable ROPS is down, DO NOT use seat belt, and drive with extra caution.

      Wide Seat Conversion Kit

      Provides additional seating room for larger operators or to accommodate cell phones or pagers. Requires seat belt extension.

      Extended Steering Levers

      Provides an additional two inches of leg clearance.

      Sunshade Canopy Aluminum

      Diamond-plated aluminum canopy is highly resistant to abrasions. Mounts to ROPS or OPS to increase operator comfort by limiting exposure to direct sunlight and reducing eye strain. Canopy tilts up and down to accommodate operator’s size. Optional cooling fan and LED light kit increase operator comfort and visibility.

      DuraFlex™ Suspension Forks

      Optional DuraFlex™ Suspension Forks absorb the impacts of rough terrain to maintain a level cut, and can be set for use with PowerVac™ collectors.

      Side Discharge Control Kit

      Control the discharge of the mower deck to avoid putting clippings in flower beds and on sidewalks

      Michelin® X® Tweel® Airless Turf Tire

      Optional 24x12.00x12 turf-tread drive tire for MidMount™ models equipped with 61- or 72-inch decks, performs like a pneumatic tire but without the inconvenience and downtime associated with flat tires. Provides consistent hub height to ensure the mower deck produces an even cut and excellent lateral stability and outstanding operator comfort. Not for use with PowerVac Collection Systems.

      Michelin® X® Tweel® Airless Front Caster Tire

      Smooth tread, 13x6.50x6 caster wheel. Performs like a pneumatic tire, but without the inconvenience and downtime associated with flats. Not for use with PowerVac Collection Systems, or with DuraFlex Suspension Forks.
