• 724 cc (44.2 cu. in.) B&S CXi engine, V-Twin, OHV engine
• Heavy-duty components enhance power and reliability
• Five-step, Integrated Cyclonic Air Management System for cleaner performance
• Extended maintenance intervals
• Three-year limited commercial engine manufacturer warranty (see dealer for details)

Design-Matched Transmission

• Design-matched, fully hydraulic Parker HTE Series integrated pump-and-wheel-motor transmissions with in-line cooling fans and fine-particle filtration
• No power-robbing gearbox or other wear parts for longer service life
• Provides best-in-class transmission fluid change interval with no break-in period, reducing costs and maintenance time

• Extra-deep, 5.5-inch deck is fabricated from heavy-gauge formed steel with a reinforced anvil edge
• Specially designed cutting chambers enhance airflow for better cut quality
• Deck easily converts from side discharge to optional Down Discharge™ mulching or PowerVac™ collection
• Sentry™ spindles with massive, 8-inch flanges anchored in a 6-bolt pattern, spread the force of impact for greater strength
• Spindle planes are fabricated from double-layered formed steel laminate and combine with the spindles to form a triple-strength deck to keep blades level and deliver a high-quality cut.
• Sentry™ spindle guards shield spindle housing and seal lower bearings from fiber wrap and dirt ingestion

• Raise and lower the deck easily with foot pedal and drop pin for precision cutting heights between 1.0 and 5.0 inches.

• Standard, low profile operator protection structure (OPS) with an adjustable seatbelt
• Dampened steering levers that return to neutral from forward and reverse
• Interlock switches that shut down the engine when the operator leaves the seat while PTO is engaged or levers are in drive position

• Unrivaled comfort with iso-mounted Ultimate Suspension Ride™ scuff-resistant, Cordura®-covered, deep-cushioned, high-back seat with padded lumbar support and armrests
• Roomy, iso-mounted, shock-absorbing footrest

• The deep-cushioned, deluxe Premium Comfort Seat features a coil-spring suspension and padded lumbar support with sliding 2-inch fore and aft adjustment for all-day comfort. Iso-mounting eliminates vibration before it reaches the seat, and both padded seat and foldable armrests are covered in scuff-resistant, breathable CoolTemp Cordura® fabric, which dissipates heat and won’t tear or crack with extended use.
• Operational controls including throttle, ignition and push/pull PTO switches, choke, angled View-Eze™ console and adjustable cup holder are well positioned for visibility and ease of reach.
• One- or two-handed operation with ComfortReach™ adjustable Hydra-Smooth™ dual levers that automatically return to neutral from either forward or reverse position.

• Only two Access-Eze™ lubrication points cut maintenance time up to 95%
• Self-tensioning belts minimize cost and labor on routine maintenance

• Robotically-welded steel construction for long-lasting durability
• Centered-bearing design provides greater load-bearing capacity to handle the weight of operator, fuel and high-capacity collector with reserve strength for curb shocks and weight shifts
• Tough-as-nails powder-coated finish is fusion-bonded for chip and rust resistance

Specifications

WEIGHT

Warranty

• Commercial Use: 2-year or 500-hour (whichever comes first); limited warranty covering parts and labor.
• Residential Use: 4-year or 500-hour (whichever comes first); limited warranty: First two years covering parts and labor, last two years covering parts only.

Options & Accessories

Foot Pedal Extension Kit

Extends foot pedals to allow easy height control for shorter operators.

4X Rear Discharge Deck

Dedicated 48--inch and larger rear discharge decks throw clippings out back for a smooth cut and no windrowing.

QuikAjust Tilt™ Levers

Available for all MidMount models, optional QuikAjust Tilt™ steering levers (except 124V-41) with "no tools" adjustment provide a 9-inch range for maximum comfort and fit while maintaining natural arm and wrist positions..

LED Work Lights

LED work lights provide improved visibility in low light situations.

Yellow Beacon Light

Yellow beacon attaches to OPS or ROPS to provide greater visibility in high-traffic areas.

TrimAide™ Vertical Roller Kit

Available for the left-hand corner of 52-inch DuraMax® decks speeds close trimming near buildings, fences retaining walls and other landscaping features.

Custom Cordura® Weather Cover

Weather-resistant, black Cordura fabric cover with embroidered Grasshopper logo keeps seat and engine area protected during storage or between mowings. Slips over ROPS, with Velcro closure to secure the opening.

DuraFlex™ Suspension Forks

Optional DuraFlex™ Suspension Forks absorb the impacts of rough terrain to maintain a level cut, and can be set for use with PowerVac™ collectors.

PowerVac® MidMount Collection System

• PowerVac™ Collection Systems deliver a clean sweep on every pass. Simply adjust your mowing speed to your conditions.
• Quik-D-Tatch® Vac drive can be removed in seconds without tools

Side Discharge Control Kit

Control the discharge of the mower deck to avoid putting clippings in flower beds and on sidewalks

Sunshade Canopy Vinyl



Lightweight, water repellent, UV-resistant vinyl canopy mounts easily to OPS or ROPS to limit exposure to direct sunlight, reducing eye strain and increasing operator comfort.

Down Discharge™ Mulching Package

The optional Down Discharge™ mulching package with GrassMax™ medium-lift blades cuts and recuts clippings and directs them deep into the grass bed, enriching turf and producing a beautifully manicured cut.

Sunshade Canopy Aluminum

Diamond-plated aluminum canopy is highly resistant to abrasions. Mounts to ROPS or OPS to increase operator comfort by limiting exposure to direct sunlight and reducing eye strain. Canopy tilts up and down to accommodate operator’s size. Optional cooling fan and LED light kit increase operator comfort and visibility.
