The deep-cushioned, deluxe Premium Comfort Seat features a coil-spring suspension and padded lumbar support for all-day comfort. Iso-mounting eliminates vibration before it reaches the seat, and both padded seat and armrests are covered in scuff-resistant, breathable CoolTemp Cordura® fabric, which dissipates heat and won’t tear or crack with extended use.
Operational controls including throttle, ignition and push/pull PTO switches, angled View-Eze™ console and adjustable cup holder are well positioned for visibility and ease of reach.
One- or two handed operation with QuikAjust Tilt™ dual levers with 9-inch comfort range to custom fit operator's reach. Levers automatically return to neutral from either forward or reverse position and are less strenuous than riding mowers with steering wheels.
PowerVac® FrontMount Collection System
Powerful, deck-driven PowerVac™ collection systems deliver one-pass perfection every time, and are available with a wide range of twin or triple mesh bag or high-capacity metal hopper collectors.
Filter Minder
The Filter Minder alerts the operator when airflow is restricted in the air canister on dual-element air filters.
Armrest Height Adjustment Switch
Used in conjunction with PowerFold® electric deck lift/height adjustment, this armrest-mounted switch controls deck lift functions and adjusts cutting height between 1.0 and 4.5 inches on the go.
Rear Discharge Shield Kit
Optional rear discharge shield kit converts 34R Series decks to direct clippings out the back of the deck for a smooth cut and no windrowing.
SpeedTrimming™ Roller Kit
The optional SpeedTrimming™ heavy-duty, anti-scalp roller kit for 52-inch and larger DuraMax® decks speeds close trimming near buildings, fences retaining walls and other landscaping features. Kits available for both left and right sides of cutting decks.
Full Flotation Deck Inserts
Allow for controlled side-to-side flotation of the deck in rolling terrain for a smooth, even cut.
Hydraulic Deck Lift
Raises the front of the deck to maneuver over soft or uneven ground and to clear curbs, trailer ramps and other obstacles. Lift switch is standard in lever on current models. Kit includes Universal Wiring Harness and requires 50-lb. counterweight and counterweight mount kit.
QuikConverter® Implements
Every FrontMount™ mower accepts a range of time- and labor-saving QuikConverter™ implements for even greater flexibility and productivity year-round.
Engine Block Heater
Engine Block Heater helps warm the engine for easier starting in cold weather.
Air Dam Kit
An optional Air Dam Kit can be installed along the front edge of most mower decks to minimize dust and dirt escaping from the front of the mower.
Wide Seat Conversion Kit
Provides additional seating room for larger operators or to accommodate cell phones or pagers. Requires seat belt extension.
WeatherBeater® Winter Enclosure
The full-view metal cab keeps moisture out and heat inside to keep the operator comfortable and productive. Standard electric windshield wiper clears windshield during operation. Powerful LED lights light up your path. Counterweight required.
Radiator Cleaning Wand
Multi-channel sprayer combs water pressure between radiator fins without damage, dislodging packed-in dust and debris that can become an invisible source of engine overheating.
Your Choice of Decks
52-, 61- or 72-inch 34 Series DuraMax® and 61-inch 36 Series (3661) side-discharge decks easily convert to Down Discharge™ mulching or PowerVac™ collection. All come standard with PowerFold® electric deck lift/height adjustment.
52-, 61- or 72-inch 35R Series and 61-inch 37R Series (3761) dedicated rear discharge decks come standard with PowerFold® electric deck lift/height adjustment
Tail Wheel Options
Dual-fork tail wheels or wide stance single-fork tail wheels.
Yellow Beacon Light
Yellow beacon attaches to OPS to provide greater visibility in high-traffic areas.
Premier Suspension Seat
Optional premier suspension seat provides the ultimate in operator comfort. Low-profile seat slides fore and aft and includes an integrated shock absorber that manually adjusts to operators between 100 – 300 lbs. Other ergonomic features include a backrest that tilts from -5 degrees to +30 degrees, a lumbar support mechanism, adjustable armrests and a retractable seat belt.
Sunshade Canopy Vinyl
Lightweight, water repellent, UV-resistant vinyl canopy mounts easily to OPS or ROPS to limit exposure to direct sunlight, reducing eye strain and increasing operator comfort.
Down Discharge™ Mulching Package
The optional Down Discharge™ mulching package with GrassMax™ High-Low Mulching blades cuts and recuts clippings and directs them deep into the turf, enriching turf and producing a beautifully manicured cut.
Extended Steering Levers
Provides an additional two inches of leg clearance.
Side Discharge Control Kit
Control the discharge of the mower deck to avoid putting clippings in flower beds and on sidewalks
Sunshade Canopy Aluminum
Diamond-plated aluminum canopy is highly resistant to abrasions. Mounts to ROPS or OPS to increase operator comfort by limiting exposure to direct sunlight and reducing eye strain. Canopy tilts up and down to accommodate operator’s size. Optional cooling fan and LED light kit increase operator comfort and visibility.
Michelin® X® Tweel® Airless Tail and Deck Wheels
Smooth tread, 13x6.50x6 tail wheel. Performs like a pneumatic tire, but without the inconvenience and downtime associated with flats. Also available for 72-inch deck wheels. Not for use with PowerVac Collection Systems.
Dedicated Rear Discharge Decks
Dedicated, extra deep rear-discharge decks deliver revolutionary performance for applications where keeping clippings off sidewalks, driveways and parking lots is critical.
Michelin® X® Tweel® Airless Turf Tire
Optional 22 x 11.00-12 turf-tread drive tire performs like a pneumatic tire but without the inconvenience and downtime associated with flat tires. Provides consistent hub height to ensure the mower deck produces an even cut and excellent lateral stability and outstanding operator comfort.
